Features

  • Unidirectional stereo condenser microphones that can record in A-B and X-Y positions
  • XLR/TRS inputs compatible with +4dBu line level / +48V
  • 4-channel mode that can be used for dual recording and nondestructive overdub recording, etc.
  • MS decoding function making it possible to use M-S microphones
  • Optional RC-3F foot switch and RC-10 wired remote control can be connected
  • Long-time operation of over 20 hours is possible using just the internal batteries
  • Reverb effect
  • Auto recording function that can detect the sound input signal level and automatically start recording
  • Proven high sound pressure design for capturing loud sounds of up to 125dB SPL
  • Peak reduction function that detects peaks and automatically sets the optimal level
  • Self timer recording function
  • Seamless gain control
  • Low-cut filter with three levels (40/80/120Hz)
  • Speed change (VSA) function for adjusting the speed from 0.5 to 1.5 times (in 0.1 increments), which is great for practicing music and language study
  • Level align feature that prevents uneven volume levels
  • Equalizer setting for adjusting playback sound quality
  • Divide/delete functions
  • Loop/repeat playback function that is convention for practicing music and studying languages
  • Resume function that retains the last stop position and starts playback from that position when power is turned back ON
  • Jump-back playback function that skips back a preset number of seconds during playback
  • QUICK menu button for easy access to various functions
  • High-quality 24-bit/96kHz WAV/BWF linear PCM recording and long recordings as MP3 files possible
  • SD/SDHC cards can be used for recording media
  • 2GB SD card is included
  • Mark function that can set up to 99 points for a single track
  • Audio files created on computers can be played (Only in formats compatible with this product)
  • Built-in monaural speaker with an output of 0.3W
  • Pre-recording buffer that can record up to 2 seconds prior to starting recording
  • When a predetermined maximum file size is reached, a new file is created to continue recording
  • Track increment creates new files at arbitrary locations during recording
  • File name format can be set to use a user-defined word or the date
  • The first six characters of the file name for recording can be set freely
  • Playlist function
  • A chromatic tuner is equipped which is helpful for practicing musical instruments
  • Stereo mini headphone line output / Headphone output connector
  • 128×64 pixel graphic LCD with backlight
  • High-speed file transfer to a computer is possible using USB 2.0
  • Powered by 2 AA batteries, USB bus power, or optional AC adapter (PS-P515U)
  • Mini USB cable included
  • Rubber feet for improving acoustic properties during desktop recordings are included
  • Tripod attachment screw-hole built in to the unit



DR-40 SPECIFICATIONS

Recording media

SD card (64MB to 2GB), SDHC card (4GB to 32GB)

File system

FAT16/32

File format

WAV,BWF,MP3

WAV / BWF

44.1/48/96kHz, 16/24bit

MP3



Sampling frequency

44.1kHz/48kHz

Bit-rate for recording

32k/64k/96k/128k/192k/256k/320kbps

Playback bit rate

32 - 320kbps, VBR, ID3 tag Ver. 2.4

Number of channels

4-channel (2 Stereo)

Playback speed control (VSA)

0.5 - 1.5 times (in 0.1 increments) * 44.1/48kHz only

Built-in microphone

Unidirectional, stereo (Possible to switch between A-B/X-Y positions)

EXT MIC/LINE IN



Connector

XLR/TRS combo jack (1: GND, 2: HOT, 3: COLD)

Input impedance

2.2k ohms(MIC) / 10k ohms(LINE)

Nominal input level

-19dBV(MIC) / +4dBu (LINE)

Maximum input level

-3dBV (MIC) / +20dBu (LINE)

PHONES/LINE OUT



Connector

1/8"(3.5mm)stereo mini jack, Unbalanced

LINE OUT



Output impedance

12ohms

Standard output level

-14dBV(10k ohms load)

Maximum output level

+2dBV(10k ohms load)

PHONES



Maximum output level

20mW+20mW(32ohms load)

Built-in speakers

0.3W, Mono

Low-cut filter

40Hz/80Hz/120Hz

USB



Connector

Mini-B type

Format

USB2.0 HIGH SPEED

REMOTE

2.5mm TRS jack

Effector

6 presets (HALL1/2, ROOM, STUDIO, PLATE1/2)

Chromatic tuner

C1 - B6, A4 = 435Hz - 445Hz (in 1Hz increments)

Tripod attachment screw-hole

1/4 inch, Tripod attachment screw-hole

Power

2 AA batteries, USB bus power, AC100 - 240V (Optional AC adapter)

Power consumption

2.5W (Max)

Battery operation time
(Recording)



With alkaline batteries
(EVOLTA)

Approx. 20.5 hours (2ch WAV, 44.1kHz, 16bit, using built-in microphone)

With Ni-MH batteries
(eneloop)

Approx. 17 hours (2ch WAV, 44.1kHz, 16bit, using built-in microphone)

Dimensions

70(W)x 155(H)x 35(D)mm

Weight

213g (Without battery)

Accessories

2GB microSD card, USB connection cable, 2 AA batteries for confirming operation, Owner's Manual, Warranty card



Audio Performance

Frequency response

20Hz-20kHz +1dB/-3dB(Fs 44.1kHz,EXT IN to LINE OUT,JEITA)
20Hz-22kHz +1dB/-3dB(Fs 48kHz,EXT IN to LINE OUT,JEITA)
20Hz-40kHz +1dB/-3dB(Fs 96kHz,EXT IN to LINE OUT,JEITA)

Distortion

0.05% or less(Fs 44.1/48/96kHz,EXT IN to LINE OUT,JEITA)

S/N ratio

92dB or more(Fs 44.1/48/96kHz,EXT IN to LINE OUT,JEITA)



Computer Requirements

Windows

OS

Windows XP,Windows Vista,Windows 7,Windows 8

CPU

Pentium 300MHz or more

Memory

128MB or more

USB

USB2.0 recommended

Macintosh

OS

Mac OS X Jaguar (V10.2),Mac OS X Panther (V10.3),Mac OS X Tiger (V10.4),
Mac OS X Leopard (V10.5),Mac OS X Snow Leopard(V10.6.8),OS X Lion(V10.7),
OS X Mountain Lion(V10.8)

CPU

Power PC,iMac,G3,G4 ,G5 266MHz or more

Memory

64MB or more

USB

USB2.0 recommended

เงื่อนไขอื่นๆ
ในกล่อง
  1.Tascam DR-40 V2
