Mooer Micro Preamp Live

Effects Pedal

• Preamp modeller
• Digital way of working
• 50 Different authentic replicas of real tube amplifiers
• 12 Independent channels in 3 banks
• 30 Different cab simulations
• Individually assignable to each channel
• Support of third-party IRs (maximum sample length 23.2 ms / 1024 points)
• TONE CAPTURE Feature to create advanced EQ stages based on sampled external amplifiers or other equipment
• MIDI compatibility
• Additional setup options via Peamp LIVE Software (Windows / Mac) or mobile mpp (Android / Apple)
• 3-Band EQ
• Integrated switchable pre / post boost
• Integrated switchable pre / post noise gate
• Integrated serial effects loop
• True bypass
• Volume, bass, mid, treble, gain and boost controls
• 1 / Source footswitch
• 2 / Target footswitch
• 3 / Capture footswitch
• 4 / Active footswitch
• Status LEDs
• Metal housing
• 6.3 mm Mono jacks IN / OUT
• 6.3 mm Mono jacks SEND / RETURN effect path
• Ground lift switch
• Balanced XLR output for connection to PA equipment or audio interfaces
• DIN-5 pin MIDI IN / OUT
• 3.5mm Stereo phone jacks output
• USB B-Socket for connection to PC and MAC
• Powered by 12V DC power adapter (not included) with 2.1mm x 5.5mm barrel and polarity (-) inside
• Power consumption: 600 mA
• Dimensions (L x W x H): 230 x 130 x 46 mm
• Weight: 1180 g
• Preamp LIVE software (compatible with Windows and Mac) and Mobile App (for Android or Apple) available online
